Tricofix 0150

Separation and filter fleece

TRICOFIX® fleeces are mechanically and thermally bonded products and are used as a protective layer for sealing. The Additionally UV-stabilized products have sufficient stability for short-term weathering during the installation period.

Application
In certain flat roof systems, the TRICOFIX® fleece takes over also provides separating functions between insulation and roof cladding so that the entire structure will function for a long time. Also used in other construction applications, such as pond construction the TRICOFIX® fleece to protect the seals from mechanical damage Damage during the construction phase and during use. In opencast tunnels or where there are high mechanical loads The heavy-duty products of the TRICOFIX® series are subject to high stress to use.

Brand

TRICOFIX

Material

PP - FASERN

Color

WEISS

Thickness

DIN EN 964-1 = 1.7 mm

Material weight

DIN EN 965 = 150 g/m2 g/m²

Tensile strength (longitudinal)

DIN EN ISO 10319 = >1.5 kN/m

Tensile strength (transverse:)

DIN EN ISO 10319 = >3 kN/m

Elongation (longitudinal)

DIN EN ISO 10319 = 100 %

Elongation (transverse)

DIN EN ISO 10319 = 80 %

Punch penetration force

ISO 12236:1996 = 0.5 kN

Tricofix 0150
